PDO Real Time Operations Well Test Systems Documentation

Collect all existing documentation for well testing and create a document contents structure followed by a gap analysis and audit of existing systems to establish latest use and alignment to latest PDO DEP specifications procedures.

Project Details

  • Contract No. C252
  • Primary Service Detailed Design & Engineering
  • Industry Oil & Gas
  • Secondary Service Control Systems Engineering, Technical Document Authoring
  • Client Petroleum Development Oman
  • Start Date Aug 2017
  • Consultant or EPC None
  • Contract Value ($) 24500
  • Project Location Al Fahal Street, Muscat 100, Oman
  • Person Hours 480
  • Execution Office Birmingham, United Kingdom
  • Status Completed

Scope of work

    Technical Authoring of Functional Design Specification for the LOWIS Well Test systems and Updating the Nibras Well Test User Guide.

Activities

  • Documents collection
  • Gap Analysis
  • Audit of existing systems documentation
  • Alignment to latest PDO procedures
  • Develop Functional Design Specification
  • Conduct Hot Review with PDO and get approval

Deliverables

  • Well Test Functional Design Specification
  • NIBRAS Well Test User Guide

Technical specifications

  • PDO DEP 00.00.07.30 - Content and drafting of a functional specification and a technical specification and the classification of products, processes and services (endorsement of ISO 13879, ISO 13880 and ISO/TR 13881)
